2GM
1-6-36
1-6-14 Removing the scanner mirr
or A
1.
Remove the ISU unit (see page 1-6-32).
2.
Remove the exposure lamp (see page 1-6-
34).
3.
Unhook two mirror A holders and then
remov
e the scanner mirror A.
Scanner mirror
A
Scanner mirror
A
Hook
Mirror A
holder
Scanner mirror
A
Hook
Mirror A
holder
Figure 1-6-43 Removing the scanner mirr
or A
