802.11n (OFDM,HT20,MCS 0-7): 6.5,13,19.5, 26, 39,52, 58.5, 72.2 Mbps
Agency approvals
US: FCC Part 15.247 Subpart C, FCC Part 15.407 Subpart E
Europe: Radio Equipment Directive 2014/53/EU
Canada: (IC) RSS-210 standard. IC 3147A-WB45NBT for Wi-Fi devices, IC 3147A-BT800 for
Bluetooth devices
Singapore: Model BT800. Manufactured by Laird, complies with IDS standards
Protocols
UDP, DHCP, TCP/IP
Data transfer
protocols
UDP/TCP/IP
Output power
39.81mW typical, country-dependent
Ancillary IEEE
standards
802.11d, 802.11e, 802.11h, 802.11i, 802.1X
1
One time passwords are not supported.
To ensure compliance with local regulations, be sure the correct country in which the
access point is installed is selected. This product can be used with the following
restriction(s):
Norway - Does not apply for the geographical area within a radius of 20 km from the
center of Ny-Ålesund.
France - Outdoor use is limited to 10 mW EIRP within the band 2454 to 2483.5 MHz.
Note Effective Isotropic Radiated Power (EIRP).
Note Some countries restrict the use of 5-GHz bands. The 802.11a radio in the
monitor uses only the channels indicated by the access point with which
the radio associates. The hospital IT department must configure access
points to operate with approved domains.
Bluetooth
®
module
Category Feature Implementation
Wireless
specification
Bluetooth 2.1 + EDR
Frequency 2.402 - 2.480 GHz
Maximum transmit power Class 1
+8 dBm from antenna
Receive sensitivity -89 dBm
Range Circa 100 meters
Data rates Up to 3 Mbps (over the air)
Host interface
USB Full speed USB 2.0
Directions for use Specifications 139
