GPIO Four configurable lines
(1.8V/3.3V configurable by VDD_PADS
Operational modes
HCI Host Controller Interface over USB
HID proxy mode Human Interface Device
EEPROM
2-wire 64K bits
Coexistence
802.11 (WiFi) Three wire CSR schemes supported
(Unity-3, Unity-3e, and Unity+)
Supply voltage
Supply 5V ± 10%
Power consumption
Current Idle mode ~5 mA
File transfer ~58 mA
Antenna option
Internal Multilayer ceramic antenna with up to 41% efficiency
Physical
Dimensions 8.5 × 13 × 1.6 mm (BT800 module)
16 × 43 × 11 (BT820 USB dongle)
Environmental
Operating -30 °C to 85 °C
Storage -40 °C to 85 °C
Miscellaneous
Lead free Lead-free and RoHS compliant
Warranty 1 year
Approvals
Bluetooth Controller subsystem approved
FCC / IC / CE All BT800 series
Configuration options
The monitor is available in multiple configurations. See the Service manual for upgrade
options available for each configuration presented below
Model
Description
7100 Base. Includes NIBP, USB, and Ethernet connectivity.
7300
Same features as 7100. Includes Bluetooth
®
wireless technology
7400 Same features as 7100. Includes Masimo or Nellcor SpO2
7500 Same features as 7400. Choice of Masimo, Nellcor, or Nonin SpO2. WiFi built in.
140 Specifications Connex
®
Spot Monitor
