Note Always grasp the hose by the connector spring tabs. Do not
pull on the hose itself.
2. Squeeze and pull the spring tabs until the connector releases.
Connect the SpO2 cable
WARNING Patient injury risk. Do not use a damaged sensor or pulse
oximetry cable or a sensor with exposed electrical or optical components.
1. On the bottom of the monitor, align the SpO2 cable connector with the cable
connector port.
2. Insert the cable connector, pressing firmly until the connector is seated.
Disconnect the SpO2 cable
1. Place your thumb and forefinger on the Sp02 cable connector. Do not grasp the
cable.
2. Pull the Sp02 cable connector out of the connector port.
Attach an accessory
CAUTION Accessories attached to this monitor must run on battery
power. Do not use any accessory's external power supply when it is
attached to the monitor.
To attach an accessory to the monitor, follow the Directions for use that
accompanied the accessory.
CAUTION Connect cables in a manner that minimizes
entangling.
Detach an accessory
To detach an accessory from the monitor, follow the instructions that accompanied
the accessory.
Disconnect AC power
CAUTION Never move the monitor or mobile stand by pulling on any of
the cords. This may cause the monitor to tip over or damage the cord.
Never pull on the power cord when disconnecting the cord from the mains
outlet. When disconnecting the power cord, always grasp the attachment
plug. Keep the cord away from liquids, heat, and sharp edges. Replace the
power cord if the strain relief, cord insulation, or metal prongs are damaged
or begin to separate from the attachment plug.
1. Grasp the power line cord.
2. Pull the power line cord from the mains outlet.
Directions for use Setup 23
