134 5 Control Panel Settings
[Ethernet]
[IPX/SPX Frame Type]
Network/Port
Ethernet
Setting Description
Ethernet Sets the communication speed and connector type for the Ethernet interface.
• [Auto] (default)
Automatically detects 100 Mbps (full duplex), 100 Mbps (half duplex), 10
Mbps (full duplex), or 10 Mbps (half duplex).
• [100 Mbps Full-Dup]
Uses 100 Mbps (full duplex).
• [100 Mbps Half-Dup]
Uses 100 Mbps (half duplex).
• [10 Mbps Full-Dup]
Uses 10 Mbps (full duplex).
• [10 Mbps Half-Dup]
Uses 10 Mbps (half duplex).
Network/Port
IPX/SPXFrameType
Setting Description
IPX/SPX Frame
Type
Sets the IPX/SPX frame type.
• [Auto] (default)
Automatically selects the frame type.
• [Ethernet II]
Uses the Ethernet frame type.
• [Ethernet 802.3]
Uses the IEEE802.3 frame type.
• [Ethernet 802.2]
Uses the IEEE802.2 frame type.
• [Ethernet SNAP]
Uses the SNAP frame type.
