A.9 Installing the TC/SC Font ROM 293
A.9 Installing the TC/SC Font ROM
This section describes how to install the TC/SC Font ROM on the printer.
1. Switch the power off by pressing the < >
side of the power switch.
2. Unplug the power cord from the power
outlet and the printer.
3. Loosen the two screws on the back right
side of the printer.
4. Pull out the handle on the control board and
then carefully pull the control board out of
the printer. Place the control board on a
table top or some other flat surface.
Important
• When pulling out the control board, hold it with both
hands so you do not drop it.
TC/SC Font ROM
To Next Page
