FreeFlow Process Manager Operator and Administrator Guide
2-131
Workflow Builder
Managing conditional branches
The Conditional Branch Settings [Name] dialog allows you to:
• View and manage existing branches for the selected
Conditional node.
• Access the Branch Conditions dialog to create and configure
new conditional branches.
To manage a conditional branch
1. In Workflow Builder, double-click a Conditional process in the
workflow to open the Conditional Branch Settings dialog.
2. Select a workflow branch.
3. Select from the following options to view, manage, and create
conditional branches:
• Conditional Set Description pane: Lists the conditions
that must be met for the selected workflow branch.
• Up arrow: Moves the selected workflow branch up one
level of order.
• Down arrow: Moves the selected workflow branch down
one level of order.
NOTE: Branches are processed from top to bottom. The first
branch conditions are checked and, if met, the branch is taken.
If not met, the next branch is checked, and so on.
• View/Edit...: Opens the Branch Conditions dialog for the
selected workflow branch. See
Adding and configuring
branch conditions.
• Delete: Removes the selected workflow branch with a
confirmation dialog.
