Maintenance
210 Xerox
®
WorkCentre
®
EC7836/EC7856 Color Multifunction Printer
User Guide
Replacing the Transfer Belt Cleaner
A message appears on the control panel when the transfer belt cleaner must be replaced.
CAUTION: Do not perform this procedure when the printer is copying or printing.
1. Open the front cover of the printer.
2. Turn the orange lever to the right to unlock the belt cleaner.
3. Turn the orange knob counterclockwise until it releases.
To Next Page
