Xinje DS5F Series User Manual

178
Parameter
Function
Unit
Default
value
Range
Effective
Suitable
mode
Reference
chapter
P5-01
Location Completion
Detection Mode
-
0
0~3
√
5|6|10
5.3.1.2
P5-02
Location completion
retention time
ms
0
0~65535
√
5|6|10
5.3.1.2
P5-03
Rotation Detection Speed
rpm
50
0~10000
√
1|2|3|4|5|6|7|
8|9|10
5.8.5.2
P5-04
Same speed detection
speed
rpm
50
0~10000
√
1|2|3|4|5|6|7|
8|9|10
5.8.5.3
P5-05
Reached detection speed
Rpm
1000
0~10000
√
1|2|3|4|5|6|7|
8|9|10
5.4.1.3
P5-06
Positioning near output
width
Command
unit
50
1~65535
√
5|6|10
5.3.1.3
P5-07
Servo OFF delay time
Ms
500
-500~999
9
○
1|2|3|4|5|6|7|
8|9|10
5.2.5
P5-08
Brake instruction output
speed
Rpm
30
20~10000
○
1|2|3|4|5|6|7|
8|9|10
5.2.5
P5-09
Brake instruction waiting
time
Ms
500
0~65535
○
1|2|3|4|5|6|7|
8|9|10
5.2.5
P5-10
user-defined output 1
trigger condition
-
0
0~ffff
√
1|2|3|4|5|6|7|
8|9|10
5.8.5.7
P5-11
Set a value that compares
with the trigger condition
of custom output 1
Relating to
trigger
condition
0
-9999~99
99
√
1|2|3|4|5|6|7|
8|9|10
5.8.5.7
P5-12
Select custom output 1
mode
-
0
0~3
√
1|2|3|4|5|6|7|
8|9|10
5.8.5.7
P5-13
Setting custom output 1
hysteresis
Relating to
trigger
condition
0
0~65535
√
1|2|3|4|5|6|7|
8|9|10
5.8.5.7
P5-14
Custom Output 2 Trigger
Condition
-
0
0~ffff
√
1|2|3|4|5|6|7|
8|9|10
5.8.5.7
P5-15
Set a value that compares
with the trigger condition
of custom output 2
Relating to
trigger
condition
0
-9999~99
99
√
1|2|3|4|5|6|7|
8|9|10
5.8.5.7
P5-16
Select custom output 2
mode
-
0
0~3
√
1|2|3|4|5|6|7|
8|9|10
5.8.5.7
P5-17
Setting custom output 2
hysteresis
Relating to
trigger
condition
0
0~65535
√
1|2|3|4|5|6|7|
8|9|10
5.8.5.7
P5-18
SI filter time multiple
-
1
0~10000
√
1|2|3|4|5|6|7|
8|9|10
5.8.4.1
P5-19
Z phase output maintain
time
ms
2
1~65535
√
1|2|3|4|5|6|7|
8|9|10
5.8.5.6
P5-20.0~1
/S-ON: servo signal
00: Set the signal to be
invalid all the time.
01: Input positive signal
from SI1 terminal.
-
01
0~ff
√
1|2|3|4|5|6|7|
8|9|10
5.2.2
