Yaesu FT2DR User Manual

127
Customize Menu Settings for Individual Use (Set Mode)
Tables of Set Mode Operations
Set mode no. / item Description
Selectable options
(Options in bold are the default settings)
Page
26 POSITION
COMMENT
Set up the position comment
function.
Off Duty / En Route / In Service
/ Returning / Committed / Special
/ Priority / Custom 0 to 6 /
EMERGENCY!
–
27 SmartBeaconing Set the smart beaconing function. STATUS: OFF / TYPE1 / TYPE2 /
TYPE3
* For details on the following
setting items for each type, refer
to the APRS Instruction Manual.
LOW SPD, HIGH SPD,
SLOW RATE, FAST RATE,
TURN ANGL, TURN SLOP,
TURN TIME
–
28 TIME ZONE Set the time zone. UTC −13:00 to UTC 0:00 to UTC
+13:00 UTC 0:00
–
* For details of the functions, refer to the APRS Instruction Manual.
SD CARD
1 BACKUP Save the data stored on the
transceiver onto a microSD memory
card or load the data from a microSD
card.
Write to SD / Read from SD 154
2 MEMORY CH Save or load the memory channel
information onto or from a microSD
memory card.
Write to SD / Read from SD 155
3 GROUP ID Save or load the GROUP ID
information onto or from a microSD
memory card.
Write to SD / Read from SD 155
4 FORMAT Initialize microSD memory cards. 31
OPTION
1 USB CAMERA Set the USB camera image size,
resolution and Speaker.
SIZE: 160*120 / 320*240
QUALITY: LOW / NORMAL /
HIGH
SP SEL: CAMERA / INT SP
157
CALLSIGN
1 CALLSIGN Set the call sign. xxxxxxxxxx 158

Yaesu FT2DR Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
GPS	Yes
Waterproof Rating	IPX5
Bluetooth	Yes
Power Output	5 W
Modes	FM, C4FM
Weight	282 g
Operating Voltage	7.4V DC
Battery	7.4 V, 2200 mAh Li-Ion
