Yaesu FT2DR User Manual

60
Using the Memory
A Wide Variety of Memory Functions
Assigning a Name to a Memory Channel
1 Press the key to enter Memory mode.
2 Recall the memory channel to assign the name.
Tip
To assign a name to a home channel, recall the desired home channel.
3 Press and hold for over one second.
The transceiver enters Set mode.
4 Touch [MEMORY].
5 Touch [3 MEMORY NAME].
6 See “Entering Letters” on page 19 to input a memory
tag.
7 Press .
The memory tag is saved to the memory channel, and the transceiver exits from Set
mode.

Yaesu FT2DR Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
GPS	Yes
Waterproof Rating	IPX5
Bluetooth	Yes
Power Output	5 W
Modes	FM, C4FM
Weight	282 g
Operating Voltage	7.4V DC
Battery	7.4 V, 2200 mAh Li-Ion
