Yaesu FT2DR User Manual

45
Basic Operation
Miscellaneous Settings
3 Touch [3 AUDIO].
4 Touch [2 MUTE].
5 Rotate the DIAL to select the desired mute setting.
Select one of the following 4 options.
• OFF
• MUTE 30%
• MUTE 50%
• MUTE 100%
The higher the value for MUTE, the more the non-operating band audio is reduced.
To deactivate the muting function, select OFF.
6 Press .
The transceiver exits from Set mode.
Remark When the muting function is activated, appears on
the LCD.
Tips
Even if the muting function is activated, the voice is not muted when no signal is received on the
operating band.

Yaesu FT2DR Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
GPS	Yes
Waterproof Rating	IPX5
Bluetooth	Yes
Power Output	5 W
Modes	FM, C4FM
Weight	282 g
Operating Voltage	7.4V DC
Battery	7.4 V, 2200 mAh Li-Ion
