4-22
6X4 MULTI-FUNCTION TILLER HANDLE
MULTI-FUNCTION TILLER HANDLE KIT (FOR EU & ANZ)
F115B
KIT P/N: 6X4-42102-C0
HANDLE IMMOBILIZER KIT CONTENTS
F30B – F115B
KIT P/N: 6Y8-W0035-C0
* Requires to replace the rigging grommet as follows.
F50 up to F60: 6C5-42725-50
F75 up to F115 (68V): 68V-42725-20
Part name Part No. Q’ty Remarks
STR friction assy 67G-42508-10 1
Stud bolt 90116-10063 2
Locknut 90185-10027 2 M10
Bracket 6EK-42121-00 1
Shift cable 6EK-48321-00 1 820 mm (33.5 in)
Clip 90468-10005 2
Cable clamp 63D-48538-00 2
Throttle cable 6EK-26301-00 1 710 mm (29.1 in)
Clamp 90464-09M42 1
10-pin main harness 6X4-82586-10 1 950 mm (37.4 in)
Clamp 90465-13M24 1
Troll RPM switch assy 6X4-81860-00 1
Part name Part No. Q’ty Remarks
Wire-harness 6Y5-83553-M0 1 2.5 m (8 ft)
Single hub 6Y8-81920-11 2
Wire-lead 6Y8-82117-00 1 For system PWR
Pigtail bus wire 6Y8-82521-51 1 3.6 m (12 ft)
Main bus wire 6Y8-82553-01 1 0.3 m (1 ft)
To Next Page
