5-29
VOLTAGE METER
The voltage meter provides info
rmation about the charging condition of the battery.
VOLTAGE METER TYP
ES AND APPLICATIONS
VOLTAGE METER DIMENSIONS
WIRING THE VO
LTAGE METER
Ref. No.
Description
Part No.
Applicable
model
1
DC 12 volt power supply
Black panel
6Y7-83503-00
All electrical start model
s
2
DC 12 volt power supply
White panel
6Y7-83503-10
12
60 (2.36)
11 (0.43)
46.6 (1.83)
13.7 (0.54)
52 (2.05)
mm (in.)
Y
B
B
L
Battery
IG switch
V
oltage meter
Batt.+12V
Y
B
Lamp switch
L
192
194
