1-12
OUTBOARD MOTOR DIMENSIONS
OVERALL DIMENSION ITEMS
Symbol Definition and Description
L1 Horizontal distance from datum point to rearmost point of power unit
L2 Horizontal distance from datum point to forefront (depends on the model) of power unit
L3
Distance from datum point to farthest point on tiller handle, when the handle is in horizontal posi-
tion (in use)
L4 Horizontal distance from datum point to rearmost point of the lower case
L5
Minimum distance from transom board or its extension to forefront of the lower case, with motor
fully trimmed down and steered to the full
L6
Horizontal distance from datum point to rearmost point of protrusion when motor is tilted up (over-
tilt position)
L7
Horizontal distance from datum point to protruded forefront when motor is tilted up (over-tilt posi-
tion)
L8
Horizontal distance from datum point to lowest point of protrusion when motor is tilted up (over-tilt
position)
L9 Horizontal forward protrusion of lower case from the datum line when PTT is fully trimmed down
L10 Horizontal distance from datum point to bracket shaft (bolt) center
H1 Vertical distance from datum point to lowest point of motor
H2 Vertical distance from datum point to highest point of power head
H3 Vertical distance from anti-cavitation plate undersurface to the center of propeller shaft
H4 Vertical distance from datum point to anti-cavitation plate undersurface
H5 Vertical distance from datum point to tiller handle tip when the handle is in vertical position
H6
Vertical distance from skeg tip at H1 to the lowest point of lower unit when motor is tilted up (over-
tilt position)
H7 Vertical distance from datum line to protruded forefront when motor is tilted up (over-tilt position)
H8
Vertical distance from datum line to lowest point of protrusion when motor is tilted up (over-tilt
position)
H9 Vertical distance to the highest point of the motor when it is tilted up (over-tilt position)
H10 Vertical distance from datum point to bracket shaft (bolt) center
H11
Difference in the height of lower unit lowest point comparing to the height in the standard position
and with PTT in the fully trimmed down position.
W1 Leftward protrusion from center line of motor body when looking at the front face
W2 Distance from tiller handle tip to centerline of motor body when looking at the front face
W3 Distance from centerline to left or right edge of motor body, except for levers and handles
W4
Distance from centerline to left or right end of motor body protrusion, except for levers and han-
dles
W5 Distance from centerline to the farthest point on the body when steered to the maximum angle
W6
Distance from centerline to the farthest point on the tiller handle when steered to the maximum
angle
A1 Maximum steering angle each way (symmetrical), from centerline of motor body
A2 Tilt up angle (whole rotating range to over-tilt angle including negative trim angle)
A3 Maximum negative trim angle from the vertical line through the datum point
T1 Centerline-to-centerline minimum distance of the engines in case of twin installation
