9-10
CONVENTIONAL RIGGING KIT CONTENTS
The rigging kit is handled by Marine Sales Division of Yamaha Motor Corporation.
Thereby, Yamaha parts distribution center in Japan is not in charge of distribution of the kit.
Attention to importers, the rigging kit must be purchased from Sales Division as well as outboard-
motors because it is impossible to purchase from the parts route.
DIGITAL TACHOMETER KIT
US/CA: Above 40, Above F30
Others: Above 40 (3-cyl) w/ oil injection (except 250G & L250G), Above F30
P/N: 6YR-W0035-E3
DIGITAL TACHOMETER AND SPEEDOMETER KIT
US/CA: Above 40, Above F30
Others: Above 40 (3-cyl) w/ oil injection (except 250G & L250G), Above F30
P/N: 6YR-W0035-F3
ANZ: Fuel injected F50-F100
P/N: 6YR-W0035-T1
Part name Part No. Q’ty Remarks
EXT wire-lead 6Y5-83653-20 1 7 m (23 ft)
Tachometer ASSY 6Y5-8350T-91 1 Included instruction tag
Wire-lead 6Y5-83553-20 1 2.5 m (8 ft) w/10 amp fuse
Part name Part No. Q’ty Remarks
Wire-lead 6Y5-83553-N0 1 2.5 m (8 ft) w/10 amp twin-fuse
Tachometer ASSY 6Y5-8350T-91 1 Included instruction tag
EXT wire-lead 6Y5-83653-30 1 8 m (26 ft)
Speedometer ASSY 6Y5-83570-S6 1 Included instruction tag
Tube 6Y5-83557-10 1 8 m (26 ft)
Clamp 90465-11M10 2
Clamp 90465-13M18 10
Instruction 61A-28107-A4 1
Part name Part No. Q’ty Remarks
Wire-lead 6Y5-82117-00 1 30 cm (1 ft), BLK
Tachometer ASSY 6Y5-8350T-91 1 Included instruction tag
Wire-lead 6Y5-83553-M0 1 2.5 m (8 ft) w/10 amp twin-fuse
Tube 6Y5-83557-10 1 8 m (26 ft)
Speedometer ASSY 6Y5-83570-S6 1 Included instruction tag
EXT wire-lead 6Y5-83653-30 1 8 m (26 ft)
Clamp 90465-11M10 2
