DIGITAL NETWORK GAUGE RIGGING KIT CONTENTS
SQUARE STYLE GAUGE RIGGING KIT FOR JAPAN
SINGLE KIT 1 (TACH)
Kit P/N: 6YR-W0035-U1
SINGLE KIT 2 (TACH, SPEED/FUEL MGT)
Kit P/N: 6YR-W0035-V7
F350 SINGLE KIT (TACH, SPEED/ FUEL MGT)
Kit P/N: 6X6-W0035-21
Part No. Part name Q’ty Remarks
6Y8-81920-01 Multi-hub 1 With resistor cap, GRY
6Y8-81920-11 Single-hub 1 With resistor
6Y8-82521-21 Pigtail bus wire, 0.9 m (3 ft) 1
6Y8-82521-41 Pigtail bus wire, 2.7 m (9 ft) 1
6Y8-82553-21 Main bus wire, 6.1 m (20 ft) 1
6Y8-82582-11 4-pin cap, WHT 2 For waterproof
6Y8-8350T-01 SQR tachometer 1
6Y8-83553-01 PWR supply wire, 2.4 m (8 ft) 1 With 10 amp fuse
6Y8-2819U-01 Operation manual 1
Part No. Part name Q’ty Remarks
60V-8A4L1-13 Speed sensor kit 1 Refer to kit contents
6Y8-81920-01 Multi-hub 1 With resistor cap, GRY
6Y8-81920-11 Single-hub 1 With resistor
6Y8-82521-21 Pigtail bus wire, 0.9 m (3 ft) 2
6Y8-82521-51 Pigtail bus wire, 3.6 m (12 ft) 1
6Y8-82553-31 Main bus wire, 7.5 m (25 ft) 1
6Y8-82582-11 4-pin cap, WHT 1 For waterproof
6Y8-83500-01 SQR comb. speedometer & fuel mgt gauge 1
6Y8-8350T-01 SQR tachometer 1
6Y8-83553-01 PWR supply wire, 2.4 m (8 ft) 1 With 10 amp fuse
6Y8-8356N-01 Fuel tank & GPS wire 1
6Y8-2819U-01 Operation manual 1
Part No. Part name Q’ty Remarks
6Y8-8350T-01 SQR Tachometer 1
6Y8-8356N-01 GPS/ Fuel tank wire 1
6Y8-83500-01 SQR Comb. Speed/ fuel mgt meter 1
6Y8-81920-01 Multi-hub 1
6Y8-85371-01 Resistor cap 1 Gray, 6-pin
6Y8-82521-21 Pigtail bus wire, 0.9 m (3 ft) 2
6Y8-82521-31 Pigtail bus wire, 1.8 m (6 ft) 1
6Y8-83553-01 PWR supply wire, 2.4 m (8 ft) 1 With 10 amp fuse
6R5-82570-06 Switch panel 1 Single
6X6-8258A-30 Main wire-harness, 10 m (32 ft) 1 16-pin
6Y8-2819U-01 Operation manual 1 Japanese
