7-12
WIRE HARNESS
CONVERSION HARNESS L
Used to connect between new DEC unit and previous main switch.
TWINNING HARNESS
Used to connect between two engine group IG switches and emergency stop SW. (For quad engine
DEC special)
CONVERSION HARNESS M (FOR 2ND HELM)
Used to connect between 2nd helm new DEC and 2nd helm previous start/stop SW. (Single engine
application)
CONVERSION HARNESS N (FOR 2ND HELM)
Used to connect between 2nd station helm new DEC and 2nd helm previous start/stop SW. (Twin
engine application)
Part No. Remarks
6X6-8258A-L0
Part No. Remarks
6X6-8258A-U0
Part No. Remarks
6X6-8258A-M0
Part No. Remarks
6X6-8258A-N0
150 (6)
YB
XX
W XPBr
XXRX
BY
Br P W
X
R
X
To
DEC
To S W
panel
mm (in.)
100 (4)
WXW
BXB
WB
WB
To emergency
stop SW
• PORT engine
group (P/CP)
• STBD engine
group (CS/S)
To main helm
SW panel
• PORT engine
group (P/CP)
• STBD engine
group (CS/S)
mm (in.)
200 (7.87)
YP
Br
W
B
X
X
X
X
Y
X
W
B
Br
P
To
DEC
To start/
stop SW
mm (in.)
240 (9.45)
X
X
P
P
Br
Br
W
B
X
X
W
B
Y
X
S
P
W
B
Br
P
Y
X
W
B
Br
P
Y
Y
To
DEC
To start/
stop SW
mm (in.)
