5-25
COOLANT TEMP. METER
COOLANT TEMP. SENSOR AND/OR
COOLANT PRESS. ATTACHMENT
INSTALLATION
(FOR 4-STROKE MODELS)
F150 (L4 2.7L)
F150C (VF150A), F165A, F175A, F200 (L4
2.8L)
ROUTING THE COOLANT TEMP. LEAD
& COOLANT PRESS. TUBE
F150 (L4 2.7L)
(1)
(2)
(1)
(2)
Coolant temp.
sensor
Coolant press.
attachment
(2) Coolant temp. sensor
(2) Coolant press. sensor
Coolant temp. lead
Coolant press. t
ub
e
Coolant press. t
ub
e
Sec
u
re coolant temp. lead first
w
ith clamp
Sec
u
re
w
ith clamp
188
190
