8-8
BATTERY WIRING
RECOMMENDED EXTENSION LENGTH OF BATTERY CABLES
If the battery cables are extended, follow the requirements in the table due to the battery capacity,
cable size and atmosphere temperature.
The length of extension battery cable means the total length of (+) and (–) cables.
Be sure to select an extension battery cable and a terminal that meet ABYC requirements or equiv-
alents.
Use a best-suited stud to the terminal size.
Solder the connection of terminals and cables to prevent them from corroding.
Coiling and/or looping battery cables should be inhibited because of a power loss.
Do not exceed the recommended extension length of battery cable.
Otherwise, the electrical system can result in poor performance or damage.
To be continued.
Atmosphere temperature is 0°C (32°F) and above
Applicable models
Battery Maximum total extension length
Unit Rating
AWG4
20 mm
2
AWG2
30 mm
2
AWG1/0
50 mm
2
AWG2/0
60mm
2
Carbureted 150 – 225
(V6-2.6L)
4-stroke 115
CCA/SAE 380 amps
3.9 m
(13 ft)
6.7 m
(22 ft)
10.3 m
(34 ft)
—
MCA/ABYC 502 amps
RC/SAE 124 min
CCA/EN 430 amps
20HR/IEC 70 Ah
JIS 65D31
4-stroke 150
CCA/SAE 512 amps
6.0 m
(20 ft)
10.0 m
(33 ft)
16.0 m
(52 ft)
—
MCA/ABYC 675 amps
RC/SAE 182 min
CCA/EN 711 amps
20HR/IEC 100 Ah
JIS 95E41
HPDI (V6-2.6L)
CCA/SAE 512 amps
8.3 m
(27 ft)
14.2 m
(47 ft)
22.0 m
(72 ft)
—
MCA/ABYC 675 amps
RC/SAE 182 min
CCA/EN 711 amps
20HR/IEC 100 Ah
JIS 95E41
4-stroke 150, 165, 175, 200
(L4-2.8L)
CCA/SAE 680 amps
2.9 m
(10 ft)
4.4 m
(14 ft)
7.3 m
(24 ft)
8.8 m
(29 ft)
MCA/ABYC 770 amps
RC/SAE 160 min
CCA/EN 640 amps
20HR/IEC 80 Ah
JIS 105D31
CCA/SAE 800 amps
3.2 m
(11 ft)
4.8 m
(16 ft)
8.0 m
(26 ft)
9.6 m
(32 ft)
MCA/ABYC 960 amps
RC/SAE 230 min
CCA/EN 750 amps
20HR/IEC 120 Ah
JIS 130E41
To Next Page
