DIGITAL NETWORK GAUGE RIGGING KIT CONTENTS
SQUARE STYLE GAUGE RIGGING KIT FOR ANZ
SINGLE KIT (TACH, SPEED, FUEL MGT)
Kit P/N: 6YR-W0035-R8
TWIN KIT (TACH)
Kit P/N: 6YR-W0035-S3
Requires the single-kit.
Part No. Part name Q’ty Remarks
60V-8A4L1-13 Speed sensor kit 1 Refer to kit contents
6Y8-81920-01 Multi-hub 1 With resistor cap, GRY
6Y8-81920-11 Single-hub 1 With resistor
6Y8-82521-11 Pigtail bus wire, 0.6 m (2 ft) 3
6Y8-82521-51 Pigtail bus wire, 3.6 m (12 ft) 1
6Y8-82553-31 Main bus wire, 7.6 m (25 ft) 1
6Y8-8350F-01 SQR fuel mgt gauge 1
6Y8-8350S-01 SQR speedometer 1
6Y8-8350T-01 SQR tachometer 1
6Y8-83553-01 PWR supply wire, 2.4 m (8 ft) 1 With 10 amp fuse
6Y8-8356N-01 Fuel tank & GPS wire 1
6Y8-2891U-20 Operation Manual 1
Part No. Part name Q’ty Remarks
61B-8258A-01 Main wire-harness 10-pin, 9.8 m (32 ft) 1
6K1-8258A-40 Main wire-harness 10-pin, 8 m (26 ft) 1
6Y8-81920-01 Multi-hub 2 With resistor cap, GRY
6Y8-82521-11 Pigtail bus wire, 0.6 m (2 ft) 1
6Y8-82521-51 Pigtail bus wire, 3.6 m (12 ft) 1
6Y8-82553-01 Main bus wire, 0.3 m (1 ft) 1
6Y8-82582-01 2-pin cap, RED 2 For waterproof
6Y8-82582-11 4-pin cap, WHT 3 For waterproof
6Y8-8350T-01 SQR tachometer 1
704-48207-P1 Twin-binnacle RCL box, Premium 1
6Y8-82570-03 Twin-switch panel 1
90149-05M05 Screw, 25 mm (1 in) 4
92990-05100 SRG washer 4
92990-05600 PLN washer 4
95380-05600 Nut 4
6Y8-2891U-20 Operation Manual 1
