8-4
BATTERY CABLE LENGTH
The following table shows the battery cable length to the (–) terminal from the grommet of outboard
motor.
The (+) terminal is usually 100 mm (4 inches) longer than the (–) terminal.
Global Model US/CA Model
Cable length (L)
Conductor cross-
sectional area
Remarks
mftAWGmm
2
E40J, EK40J 1.43 4.7 5 15
55B 1.47 4.8 5 15
40V, 50H, FT50C, F50D 1.64 5.4 8 8
F30B, F40F F30A, F40A 1.64 5.4 5 15
US, CA, ANZ & JP:
2.24 m (7.3 ft)
E/40X, 9.9F, 15F 1.67 5.5 8 8
F20D, F25D F25A/B 1.67 5.5 5 15 JP: 2.08 m (6.7 ft)
FT25F T25A 2.24 7.3 5 15
E/25B, E/30H, 30D 1.70 5.6 8 8
6C, 8C, 20D, 25N, F8C, FT8D F8A 1.75 5.7 8 8
F15C, F20B F15A, F20A 1.77 5.8 8 8
60F, 70B 1.78 5.8 5 15 ANZ: 2.38 m (7.8 ft)
75C, 90A 2.14 7.0 5 15
F70A, F40G F70A 2.24 7.3 8 8
F40H, F50H, FT50J, F60F,
FT60G
F50B, T50B, F60B, T60B 2.29 8 8 8 US, CA: 2.29 m (8 ft)
115B, 140B 2.42 7.9 5 15
Carbureted V6-2.6L w/ oil
injection
Carbureted V6-2.6L w/ oil
injection
2.59 8.5 5 15
HPDI V6-2.6L HPDI V6-2.6L 2.61 8.6 2 30
FT8D (RC) 2.65 8.7 8 8
F9.9J, FT9.9L F9.9B, T9.9B 2.75 9 8 8 JP: 1.85 m (6 ft)
E115A 2.76 9.1 5 15
F75B, F80B, F90B, F95A,
F100B, F100D, F75C,
F/FL115A
F75A, F90A, F/LF115A 2.83 9.3 5 15
115C, 130B 2.88 9.4 5 15
L/150A, L/200A 2.93 9.6 5 15
L/250G 3.31 10.9 2 30
Global Model US/CA/ANZ Model
Cable length (L)
Conductor cross-
sectional area
Remarks
mftAWGmm
2
F/FL150A, F/FL150B, F150C,
F165A, F175A, F/FL200F,
F/FL200G
F/LF150A, VF150A, F175A,
F/LF200B, F/FL200G
2.61 8.6 2 30
F/FL115B F/LF115B 2.83 9.3 5 15
F/FL200B, F/FL200C, F/
FL225B, F225C, F/FL250A, F/
FL250G
F200D, F225D, F250C,
F225G, F250F, F275A
F/FL225F, F/FL250D, F/
FL300B
F/LF200A, F/LF225A, F/
LF250A
VF200LA, VF225LA, VF250LA
F/LF225CA, F/LF250CA,
F/LF300CA
3.50 11.5 2 30
F/FL350A F/LF350CB 3.56 11.7 2/0 60
