6-2
DIGITAL NETWORK GAUGE COMPATIBLE MODELS
The following models can accept the digital network gauges.
Electronic fuel injected 4-stroke engines
HPDI engines
* US & Canada: 2006 and later models
* Others: 2007 and later models
Also, those engines can accept the conventional gauges 6Y5 and 6Y7 (square meters are not com-
patible with DEC engines).
Therefore, you must select one of two gauge systems.
If you select the digital network gauge system, see the information below.
For further information, see the applicable service guide, installation manual, etc.
DIGITAL NETWORK GAUGE APPLICATION
SQUARE STYLE GAUGE APPLICATION
Large digital display and dot matrix expression design.
Ref. No. Part name Part No. Remarks
1 Tachometer 6Y8-8350T-01
2 Speedometer 6Y8-8350S-01
Requires optional speed sensor, or NMEA compatible
GPS
3 Fuel management gauge 6Y8-8350F-01
4
Speedometer and Fuel meter
unit
6Y8-83500-01
Requires optional speed sensor, or NMEA compatible
GPS
To Next Page
