Remote Commands
1
2
3
4
5
6
7
8
App
Index
:APPLication:DLOGging:LPARameter:TLO
Gging
Function Sets or queries whether waveforms will be
logged during data logging.
Syntax
:APPLication:DLOGging:LPARameter:TL
OGging<wsp>OFF|ON|0|1
:APPLication:DLOGging:LPARameter:TL
OGging?
OFF = Waveform data save function off
ON = Waveform data save function on
Example
:APPLICATION:DLOGGING:LPARAMETER:TL
OGGING OFF
:APPLICATION:DLOGGING:LPARAMETER:TL
OGGING? -> 0
Description • This command is invalid when data logging is
in progress.
• This is a sequential command.
• This command can be used on the AQ6370C/
AQ6370D/AQ6373B/AQ6375B.
:APPLication:DLOGging:STATe
Function Starts, stops, or queries data logging.
Syntax
:APPLication:DLOGging:STATe<wsp>STO
P|STARt|0|1
:APPLication:DLOGging:STATe?
START = Starts data logging
STOP = Stops data logging
Response 0 = Stopped, 1 = Running
Example
:APPLICATION:DLOGGING:STATE 1
:APPLICATION:DLOGGING:STATE? -> 1
Description • Only the following commands are valid when
data logging is in progress.
• Common commands (excluding *TRG
and *TST)
• All query commands
• ABORt
• This is an overlappable command.
• This command can be used on the AQ6370C/
AQ6370D/AQ6373B/AQ6375B.
CALCulate Sub System Command
Outline
• Commands about the following functions are
summarized in this sub system.
• Analysis function (Spectrum Width,
ANALYSIS1 , ANALYSIS2)
• Peak/Bottom search function
• Marker function (
Δ
marker, line marker)
• Calculation function of trace
• Advanced marker function (moving marker,
power spectral density marker, integrated
power marker)
• The following procedure is performed in order to
carry out remote control of the Analysis function.
1. Select the analysis algorithm
(
CALCulate:CATegory
command)
2 Set the Analysis Parameter
(
CALCulate:PARameter
command)
3 Execute the analysis function
(
CALCulate[:IMMediate]
command)
4 Get the analysis results (
CALCulate:DATA?
command)
• The following command is used in order to carry out
remote control of the Peak/Bottom search function.
CALCulate:MARKer:MAXimum|MINimum
command
• The following command is used to in order to carry
out remote control of the Marker function.
 Δmarker:
CALCulate:MARKer
command
Line marker:
CALCulate:LMARker
command
• The following command is used to in order to carry
out remote control of the trace Calculation function.
CALCulate:MATH
command
:CALCulate:AMARker[1|2|3|4]:AOFF
Function Clears all advanced markers (moving markers,
power spectral density markers, and integrated
power markers) and turns off the advanced
marker function.
Syntax
:CALCulate:AMARker[1|2|3|4]:AOFF
[1|2|3|4]: Advanced marker number
Example
:CALCULATE:AMARKER:AOFF
Description • After clearing, the advanced marker function
automatically turns off.
• All advanced markers are cleared regardless
of which advanced marker you specify.
• This is a sequential command.
• This command can be used on the AQ6370C/
AQ6370D/AQ6373B/AQ6375B.
7.6 Instrument-Specific Commands
