7.3 ANALYSIS Setting Parameters
In setting ANALYSIS key setting parameters, the analysis parameters differ with the
analysis type. Thus, the PARAMETER SETTING key commands are set independently
of the regular key commands. An analysis parameter setting command is shown below.
SPEC WIDTH
ANALYSIS Parameters Control Command
THRESH
THRESH LEVEL **.**dB
:CALCulate:PARameter[:CATegory]:SWTHresh:TH<wsp
><NRf>[DB]
K **.**
:CALCulate:PARameter[:CATegory]:SWTHresh:K<wsp>
<NRf>
MODE FIT ON/OFF
:CALCulate:PARameter[:CATegory]:SWTHresh:MFIT<w
sp>OFF|ON|0|1
ENVELOPE
THRESH LEVEL1**.**dB
:CALCulate:PARameter[:CATegory]:SWENvelope:TH1<
wsp><NRf>[DB]
THRESH LEVEL2 **.**dB
:CALCulate:PARameter[:CATegory]:SWENvelope:TH2<
wsp><NRf>[DB]
K **.**
:CALCulate:PARameter[:CATegory]:SWENvelope:K
PEAK RMS
THRESH LEVEL **.**dB
:CALCulate:PARameter[:CATegory]:SWPKrms:TH<wsp>
<NRf>[DB]
K **.**
:CALCulate:PARameter[:CATegory]:SWPKrms:K<wsp><
NRf>[DB]
NOTCH
THRESH LEVEL **.**dB
:CALCulate:PARameter[:CATegory]:NOTCh:TH<wsp><N
Rf>[DB]
K **.**
:CALCulate:PARameter[:CATegory]:NOTCh:K<wsp><NR
f>[DB]
Type
PEAK
:CALCulate:PARameter[:CATegory]:NOTCh:TYPE<wsp>
PEAK|0
BOTTOM
:CALCulate:PARameter[:CATegory]:NOTCh:TYPE<wsp>
BOTTom|1
ANALYSIS 1
ANALYSIS Parameters Control Command
DFB-LD
-XdB WIDTH
ALGO
:CALCulate:PARameter[:CATegory]:DFBLd<wsp>SWIDth,
ALGO,<data>
THRESH **.**dB
:CALCulate:PARameter[:CATegory]:DFBLd<wsp>
SWIDth,TH,<NRf>[DB]
THRESH2 **.**dB
:CALCulate:PARameter[:CATegory]:DFBLd<wsp>SWIDth,
TH2,<NRf>[DB]
K
:CALCulate:PARameter[:CATegory]:DFBLd<wsp>SWIDth,
K,<NRf>
MODE FIT ON/OFF
:CALCulate:PARameter[:CATegory]:DFBLd<wsp>
SWIDth,MFIT,OFF|ON|0|1
MODE DIFF *.**dB
:CALCulate:PARameter[:CATegory]:DFBLd<wsp>
SWIDth,MDIFf,<NRf>[DB]
SWIDth
ALGO
:CALCulate:PARameter[:CATegory]:DFBLd
<wsp>SWIDth,ALGO,<data>
THRESH **.**dB
:CALCulate:PARameter[:CATegory]:DFBLd
<wsp>SWIDth,TH,<NRf>[DB]
To Next Page
