2.3 GP-IB Interface Specifications
GP-IB Interface Specifications
Electromechanical specifications: Conforms to IEEE std. 488-1978
Functional specifications: See table below
Protocols: Conforms to IEEE std. 488.2-1992
Encoding: ISO (ASCII)
Mode: Addressable mode
Address setting: Addresses 0 to 30 can be set in the GP-IB setting
screen in the SYSTEM menu.
Remote mode cancel: Press LOCAL to cancel Remote mode. Note that
this is disabled when under Local Lockout by the
controller.
Functional Specifications
Function Subset Description
Source handshake SH1 All capabilities of send handshake
Acceptor handshake AH1 All capabilities of receive handshake
Talker T6 Basic talker function, serial polling, and talker
cancel function through MLA (my listen address).
Talker only not provided.
Listener L4 Basic listener function, serial polling, and listener
cancel function through MLA (my listen address).
Listener only not provided.
Service request SR1 All service request functions
Remote local RL1 All Remote/Local functions
Parallel port PP0 Parallel polling function not provided
Device clear DC1 All device clear functions
Output buffer clear
Input buffer clear (clearing of an unexecuted
commands)
Error buffer clear
STB, ESR clear
Device trigger DT0 Device trigger function
Controller C0 Controller function not provided
Electrical characteristics E1 Open collector
