6-2
IM AQ6370C-17EN
Status Register Overview Diagram
Standard Event Status
Operation Status
Questionable Status
bit 7
bit 6
bit 5
bit 4
bit 3
bit 2
bit 1
bit 0
Power on
Unused
Command error
Execution error
Device dependency error
Query error
Unused
Operation complete
bit 7
bit 6
bit 5
bit 4
bit 3
bit 2
bit 1
bit 0
bit 15
bit 14
bit 13
bit 12
bit 11
bit 10
bit 9
bit 8
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Auto Sweep
Cal/Alignment
Copy/File
Program
Sweep
bit 7
bit 6
bit 5
bit 4
bit 3
bit 2
bit 1
bit 0
bit 15
bit 14
bit 13
bit 12
bit 11
bit 10
bit 9
bit 8
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
bit 7
bit 6
bit 5
bit 4
bit 3
bit 2
bit 1
bit 0
Output buffer
Status Byte
OPS
RQS/MSS
ESB
MAV
QUS
Unused
Unused
Unused
6.1 Status Registers
