3.2 Setting Up Ethernet
Procedure
Selecting the Communication Interface
1.
Press SYSTEM. The system setting menu is displayed.
2.
Press the MORE1/4 soft key. The communication interface setting menu is
displayed.
3.
Press the REMOTE INTERFACE soft key. The setting menu for the interface to
be used is displayed.
4.
In AQ6370D (R02.01 or later), press the
NETWORK(SOCKET)
or
NETWORK(VXI-11)
soft key to set the communication interface to Ethernet.
In models other than AQ6370D, press the ETHERNET soft key to set the
communication interface to Ethernet.
NETWORK(SOCKET)(AQ6370D)
NETWORK(except for AQ6370D)
NETWORK(VXI-11)(AQ6370D)
Setting Up TCP/IP
5.
Press the NETWORK SETTING soft key. The ethernet setting menu is displayed.
6.
Press the TCP/IP SETTING soft key. The TCP/IP setting menu is displayed.
7.
Using the <, > soft keys, select AUTO (DHCP) or MANUAL.
8.
Press the SELECT soft key. The item is selected.
To Next Page
