YOKOGAWA AQ6370C User Manual

7-4
IM AQ6370C-17EN
7.2 Table of Correspondence between Soft Keys
and Remote Commands
The tables below list the remote commands that correspond to the soft keys used when
manipulating the various settings of the instrument.
For the AQ6370C, AQ6370D, AQ6373, AQ6373B, AQ6375, and AQ6375B if commands
are valid for only some of the instruments, the models are indicated in the remarks
column. Models are not noted for commands that are valid for all instruments.
SWEEP
Function Control Command
AUTO
:INITiate:SMODe<wsp>AUTO|3;:INITiate
REPEAT
:INITiate:SMODe<wsp>REPeat|2;:INITiate
SINGLE
:INITiate:SMODe<wsp>SINGle|1;:INITiate
STOP
:ABORt
SEGMENT MEASURE
:INITiate:SMODe<wsp>SEGment|4;:INITiate
SEGMENT POINT*****
:SENSe:SWEep:SEGMent:POINts<wsp><integer>
SWEEP MKR L1-L2 ON/OFF
:SENSe:WAVelength:SRANge<wsp>OFF|ON|0|1
SWEEP INTVL *****sec
:SENSe:SWEep:TIME:INTerval<wsp><integer>[SEC]
CENTER
Function Control Command Remarks
CENTER WL ****.***nm
:SENSe:WAVelength:CENTer<wsp><NRf>[M]
CENTER FREQ ***.****THz
:SENSe:WAVelength:CENTer<wsp><NRf>[HZ]
CENTER WNUM ****.***cm
-1
:SENSe:WAVelength:CENTer<wsp><NRf>
AQ6375
START WL ****.***nm
:SENSe:WAVelength:STARt<wsp><NRf>[M]
START FREQ ***.****THz
:SENSe:WAVelength:STARt<wsp><NRf>[HZ]
STOP WNUM ****.***cm
-1
:SENSe:WAVelength:STARt<wsp><NRf>
AQ6375
STOP WL ****.***nm
:SENSe:WAVelength:STOP<wsp><NRf>[M]
STOP FREQ ***.****THz
:SENSe:WAVelength:STOP<wsp><NRf>[HZ]
START WNUM ****.***cm
-1
:SENSe:WAVelength:STOP<wsp><NRf>
AQ6375
PEAK→CENTER
:CALCulate:MARKer:SCENter
AUTO CENTER ON/OFF
:CALCulate:MARKer:MAXimum:SCENter:AUTO
<wsp>OFF|ON|0|1
VIEW→MEAS
:DISPlay[:WINDow]:TRACe:X[:SCALe]:SMSCale
SPAN
Function Control Command Remarks
SPAN****.*nm
:SENSe:WAVelength:SPAN<wsp><NRf>[M]
SPAN WNUM****.*cm
-1
:SENSe:WAVelength:SPAN<wsp><NRf>
AQ6375
START WL****.***nm
:SENSe:WAVelength:STARt<wsp><NRf>[M]
START FREQ***.****THz
:SENSe:WAVelength:STARt<wsp><NRf>[HZ]
START WNUM****.***cm
-1
:SENSe:WAVelength:STARt<wsp><NRf>
AQ6375
STOP WL****.***nm
:SENSe:WAVelength:STOP<wsp><NRf>[M]
STOP FREQ***.****THz
:SENSe:WAVelength:STOP<wsp><NRf>[HZ]
STOP WNUM****.***cm
-1
:SENSe:WAVelength:STOP<wsp><NRf>
AQ6375
0nm SWEEP TIME**sec
:SENSe:SWEep:TIME:0NM<wsp><integer>[SEC]
VIEW→MEAS
:DISPlay[:WINDow]:TRACe:X[:SCALe]:SMSCale
