5.2 GP-IB Interface Specifications
GP-IB Interface Specifications
Electromechanical specifications: Conforms to IEEE std. 488-1978
Functional specifications: See table below
Protocols: Conforms to IEEE std. 488.2-1992
Encoding: ISO (ASCII)
Mode: Addressable mode
Address setting: Addresses 0 to 30 can be set in the GP-IB
setting screen in the SYSTEM menu.
Remote mode cancel: Press LOCAL to cancel Remote mode. Note
that this is disabled when under Local Lockout
by the controller.
Functional Specifications
Function Subset Description
Source handshake SH1 All capabilities of send handshake
Acceptor handshake AH1 All capabilities of receive handshake
Talker T4 Basic talker function
Listener L2 Basic listener function
Service request SR0 Service request function not provided
Remote local RL0 Local lockout function not provided
Parallel port PP0 Parallel polling function not provided
Device clear DC0 Device clear function not provided
Device trigger DT0 Device trigger function
Controller C1 System controller IFC transmission
C2 Controller in charge
C3 REN transmission
C28 Interface message transmission
Electrical characteristics E1 Open collector
