126 Parameters
Started Bit 5 of 06.16 Drive status word 1.5
Magnetized Bit 1 of 06.17 Drive status word 2.6
Running Bit 6 of 06.16 Drive status word 1.7
Ready ref Bit 2 of 06.11 Main status word.8
At setpoint Bit 8 of 06.11 Main status word.9
Reverse Bit 2 of 06.19 Speed control status word.10
Zero speed Bit 0 of 06.19 Speed control status word.11
Above limit Bit 10 of 06.17 Drive status word 2.12
Warning Bit 7 of 06.11 Main status word.13
Fault Bit 3 of 06.11 Main status word.14
Fault (-1) Inverted bit 3 of 06.11 Main status word.15
Fault/Warning A warning or fault is active. 16
Overcurrent A drive is tripped to overcurrent fault. 17
Overvoltage A drive is tripped to overvoltage fault. 18
Drive temp A drive is tripped to drive temperature fault. 19
Undervoltage A drive is tripped to undervoltage fault. 20
Motor temp A drive is tripped to motor temperature fault. 21
Brake command Bit 0 of 44.01 Brake control status. 22
Ext2 active Bit 11 of 06.16 Drive status word 1.23
Remote control Bit 9 of 06.11 Main status word.24
Supervision 1 Bit 0 of 32.01 Supervision status.33
Supervision 2 Bit 1 of 32.01 Supervision status.34
Supervision 3 Bit 2 of 32.01 Supervision status.35
Start delay Bit 13 of 06.17 Drive status word 2.39
RO/DIO control word
bit0
Bit 0 of 10.99 RO/DIO control word.40
Event word 1 Parameter 04.40 Event word 1.53
User load curve Bit 3 (Outside load limit) of 37.01 ULC output status word
(see page 231).
61
RO/DIO control word Maps to corresponding bit in parameter 10.99 RO/DIO
control word. For example, Bit 0 of 10.99 RO/DIO control
word controls RO1.
62
Other [bit] Source selection (see Terms and abbreviations). -
No. Name/Value Description Default
FbEq 16
ACS180 FW.book Page 126 Tuesday, March 9, 2021 2:25 PM
