282 Parameters
96.55 Checksum control
word
Bits 8…9 select which comparison(s) are made:
• Bit 8 = 1 (Approved checksum A):
96.68 Actual
checksum A is compared to 96.71 Approved checksum
A, and/or
• Bit 9 = 1 (Approved checksum A):
if 96.69 Actual
checksum B is compared to 96.72 Approved checksum
B.
Bits 12…13 select approved (reference) checksum
parameter(s) into which the actual checksum(s) from
parameter(s) are copied:
• Bit 12 = 1 (Set approved checksum A):
Value of 96.68
Actual checksum A is copied into 96.71 Approved
checksum A and/or
• Bit 13 = 1 (Set approved checksum B):
Value of 96.69
Actual checksum B copied into 96.72 Approved
checksum B.
0b0000
0b0000...0b1111 Checksum control word. 1 = 1
96.68 Actual checksum A Displays the actual parameter configuration checksum A.
The checksum A is generated and updated whenever an
action is selected in 96.54 Checksum action and 96.55
Checksum control word, bit 8 = 1 (Approved checksum A)
The set of parameters for checksum A calculation does
not include fieldbus settings parameters.
The parameters included in the checksum A calculation
are user editable parameters in parameter groups 10, 15,
19, 20, 21, 22, 23, 24, 25, 28, 30, 31, 32, 35, 36, 37, 40,
41, 45, 46, 71, 95, 96, 97, 98, and 99.
See also section Parameter checksum calculation (page
98).
0x0000
0x0000...0xffff Actual checksum A. 1 = 1
No. Name/Value Description Default
FbEq 16
Bit Name Information
0...7 Reserved
8 Approved checksum A 1 = Enabled: Checksum A (96.71) is observed. 0 =
Disabled.
9 Approved checksum B 1 = Enabled: Checksum B (96.72) is observed. 0 =
Disabled.
10...11 Reserved
12 Set approved checksum A 1 = Set: Copy value of 96.68 into 96.71. 0 = Done (copy has
been made).
13 Set approved checksum B 1 = Set: Copy value of 96.69 into 96.72. 0 = Done (copy has
been made).
14...15 Reserved
ACS180 FW.book Page 282 Tuesday, March 9, 2021 2:25 PM
