Parameters 283
96.69 Actual checksum B Displays the actual parameter configuration checksum B.
The checksum B is generated and updated whenever an
action is selected in 96.54 Checksum action and 96.55
Checksum control word, bit 9 = 1 (Approved checksum B)
The set of parameters for checksum B does not include:
• fieldbus settings
• motor data settings, and
• energy data settings parameters.
The parameters included in the checksum B calculation
are user editable parameters in parameter groups 10, 15,
19, 20, 21, 22, 23, 24, 25, 28, 30, 31, 32, 35, 36, 37, 40,
41, 46, 71, 95, 96, and 97.
See also section Parameter checksum calculation (page
98).
0x0000
0x0000...0xffff Actual checksum B. 1 = 1
96.71 Approved checksum A Approved (reference) checksum A. 0x0000
0x0000...0xffff Approved checksum A. -
96.72 Approved checksum B Approved (reference) checksum B. 0x0000
0x0000...0xffff Approved checksum B. -
96.78 550 compatibility
mode
Enables/disables a Modbus user to access a select set of
parameters using 550 register numbering.
See the supported parameters in section Parameters
supported by Modbus backwards compatibility with 550
on page 298.
Disabled
Disable Using 550 compatibility mode is disabled 0
Enable Using 550 compatibility mode is enabled 1
96.100 Change user pass
code
(Visible when user lock is open)
To change the current user pass code, enter a new code
into this parameter as well as 96.101 Confirm user pass
code. A warning A6B1 will be active until the new pass
code is confirmed. To cancel changing the pass code,
close the user lock without confirming. To close the lock,
enter an invalid pass code in parameter 96.02 Pass code,
activate parameter 96.08 Control board boot, or cycle the
power.
See also section User lock (page 100).
10000000
10000000…
99999999
New user pass code. -
96.101 Confirm user pass
code
(Visible when user lock is open)
Confirms the new user pass code entered in 96.100
Change user pass code.
10000000…
99999999
Confirmation of new user pass code. -
No. Name/Value Description Default
FbEq 16
ACS180 FW.book Page 283 Tuesday, March 9, 2021 2:25 PM
