ABB ACS380 Series User Manual

Parameters 263
Frequency The scaling is defined by parameter 46.02 Frequency
scaling.
5
50.05 FBA A ref2 type Selects the type and scaling of reference 2 received from
fieldbus adapter A. The scaling of the reference is defined
by parameters 46.01…46.04, depending on which
reference type is selected by this parameter.
Speed or
frequency
Speed or frequency Type and scaling is chosen automatically according to the
currently active operation mode as follows:
0
Transparent No scaling is applied. 1
General Generic reference without a specific unit. 2
Torque The scaling is defined by parameter 46.03 Torqu e sc a l ing .3
Speed The scaling is defined by parameter 46.01 Speed scaling.4
Frequency The scaling is defined by parameter 46.02 Frequency
scaling.
5
50.06 FBA A SW sel Selects the source of the status word to be sent to the
fieldbus network through fieldbus adapter A.
Auto
Auto Source of the status word is chosen automatically. 0
Transparent mode The source selected by parameter 50.09 FBA A SW
transparent source is transmitted as the status word to the
fieldbus network through fieldbus adapter A.
1
50.07 FBA A actual 1 type Selects the type and scaling of actual value 1 transmitted
to the fieldbus network through fieldbus adapter A. The
scaling of the value is defined by parameters
46.01…46.04, depending on which actual value type is
selected by this parameter.
Speed or
frequency
Speed or frequency Type and scaling is chosen automatically according to the
currently active operation mode as follows:
0
Transparent No scaling is applied. 1
General Generic reference without a specific unit. 2
Torque The scaling is defined by parameter 46.03 Torqu e sc a l ing .3
Speed The scaling is defined by parameter 46.01 Speed scaling.4
Frequency The scaling is defined by parameter 46.02 Frequency
scaling.
5
No. Name/Value Description Default
FbEq 16
Operation mode
(see par. 19.01)
Reference 2 type
Speed control Torque
Torque control Torque
Frequency control Torque
Operation mode
(see par. 19.01)
Actual value 1 type
(source)
Scaling
Speed control
Speed
(01.01 Motor speed used)
46.01 Speed scaling
Torque control
Frequency control
Frequency
(01.06 Output frequency)
46.02 Frequency scaling
