264 Parameters
50.08 FBA A actual 2 type Selects the type and scaling of actual value 2 transmitted
to the fieldbus network through fieldbus adapter A. The
scaling of the value is defined by parameters
46.01…46.04, depending on which actual value type is
selected by this parameter.
Speed or
frequency
Speed or frequency Type and scaling is chosen automatically according to the
currently active operation mode as follows:
0
Transparent The value selected by parameter 50.11 FBA A act2
transparent source is sent as actual value 2. No scaling is
applied (the 16-bit scaling is 1=1 unit).
1
General The value selected by parameter 50.11 FBA A act2
transparent source is sent as actual value 2 with a 16-bit
scaling of 100=1 unit (i.e. integer and two decimals).
2
Torque 01.01 Motor speed used is sent as actual value 2. The
scaling is defined by parameter 46.03 Torque scaling.
3
Speed 01.01 Motor speed used is sent as actual value 2. The
scaling is defined by parameter 46.01 Speed scaling.
4
Frequency 01.06 Output frequency is sent as actual value 2. The
scaling is defined by parameter 46.02 Frequency scaling.
5
50.09 FBA A SW transparent
source
Selects the source of the fieldbus status word when
parameter 50.06 FBA A SW sel is set to Transparent
mode.
Not selected
Not selected No source selected. -
Other Source selection (see Terms and abbreviations). -
50.10 FBA A act1
transparent source
When parameter 50.07 FBA A actual 1 type is set to
Transparent, this parameter selects the source of actual
value 1 transmitted to the fieldbus network through
fieldbus adapter A.
Not selected
Not selected No source selected. -
Other Source selection (see Terms and abbreviations). -
50.11 FBA A act2
transparent source
When parameter 50.08 FBA A actual 2 type
is set to
Transparent, this parameter selects the source of actual
value 2 transmitted to the fieldbus network through
fieldbus adapter A.
Not selected
Not selected No source selected. -
Other Source selection (see Terms and abbreviations). -
50.12 FBA A debug mode This parameter enables debug mode. Displays raw
(unmodified) data received from and sent to fieldbus
adapter A in parameters 50.13…50.18.
Disable
Disable Debug mode disabled. 0
No. Name/Value Description Default
FbEq 16
Operation mode
(see par. 19.01)
Actual value 2 type Scaling
Speed control
Speed
(01.01 Motor speed used)
46.01 Speed scaling
Torque control
Frequency control
Frequency
(01.06 Output frequency)
46.02 Frequency scaling
