Additional parameter data 341
71.39 Deadband range Real 0.0…32767.0 - 10 = 1
71.40 Deadband delay Real 0.0…3600.0 s 10 = 1 s
71.58 Increase prevention List 0…3 - 1 = 1
71.59 Decrease prevention List 0…3 - 1 = 1
71.62 Internal setpoint actual Real -32768.00…32767.00 rpm,% or
Hz
100 = 1 unit
76 Application features
76.01 Limit to limit control status List 0...5 - 1 = 1
76.02 Limit to limit enable List 0...29 - 1 = 1
76.03 Limit to limit control mode List 0...1 - 1 = 1
76.04 Forward stop limit List 0...29 - 1 = 1
76.05 Forward slow down limit List 0...29 - 1 = 1
76.06 Reverse stop limit List 0...29 - 1 = 1
76.07 Reverse slow down limit List 0...29 - 1 = 1
76.08 Slow down speed Real 0.00…30000.00 rpm 1 = 1
76.09 Slow down frequency Real 0.00…500.00 Hz 1 = 1
90 Feedback selection
90.01 Motor speed for control Real -32768.00 … 32767.00 rpm 100 = 1 rpm
90.02 Motor position Real 0.00000000 … 1.00000000 rev 100000000 =
1rev
90.10 Encoder 1 speed Real -32768.00 … 32767.00 rpm 100 = 1 rpm
90.11 Encoder 1 position Real 0.00000000 … 1.00000000 rev 100000000 =
1rev
90.13 Encoder 1 revolution
extension
Real -2147483648 …
2147483647
-1 = 1
90.41 Motor feedback selection List 0…2 - 1 = 1
90.42 Motor speed filter time Real 0…10000 ms 1 = 1 ms
90.45 Motor feedback fault List 0…1 - 1 = 1
90.46 Force open loop List 0…1 - 1 = 1
90.47 Enable motor encoder drift
detection
List 0…1 - 1 = 1
91 Encoder adapter settings
91.02 Adapter 1 status List --1 = 1
91.10 Encoder parameter refresh List 0…1 - 1 = 1
92 Encoder 1 configuration
92.10 Pulses/revolution Real 0…65535 - 1 = 1
95 HW configuration
95.01 Supply voltage List 0…5 - 1 = 1
95.02 Adaptive voltage limits List 0…1 - 1 = 1
95.03 Estimated AC supply voltage Real 0…65535 - 1 = 1 V
95.04 Control board supply List 0…1 - 1 = 1
95.15 Special HW settings List 0…1 . 1 = 1
