342 Additional parameter data
95.20 HW options word 1 PB 0000h…FFFFh - 1 = 1
96 System
96.01 Language List --1 = 1
96.02 Pass code Data 0…99999999 - 1 = 1
96.03 Access levels status PB 000b…111b - 1 = 1
96.04 Macro select List 0…3, 11…14 - 1 = 1
96.05 Macro active List 1…3, 11…14 - 1 = 1
96.06 Parameter restore List 0, 8, 62 - 1 = 1
96.07 Parameter save manually List 0…1 - 1 = 1
96.08 Control board boot Real 0…1 - 1 = 1
96.10 User set status List 0…7, 20…23 - -
96.11 User set save/load List 0…5, 18…21 - -
96.12 User set I/O mode in1 Binary src ---
96.13 User set I/O mode in2 Binary src ---
96.16 Unit selection PB 000h…FFFFh - 1 = 1
96.51 Clear fault and event logger Real 0...1 - 1 = 1
96.70 Disable adaptive program Real 0...1 - 1 = 1
(Parameters 96.100…96.102 only visible when enabled by parameter 96.02)
96.100 Change user pass code Data 10000000…99999999 - 1 = 1
96.101 Confirm user pass code Data 10000000…99999999 - 1 = 1
96.102 User lock functionality PB 0000h…FFFFh - 1 = 1
97 Motor control
97.01 Switching frequency
reference
List 4…12 kHz 1 = 1
97.02 Minimum switching frequency List 1…12 kHz 1 = 1
97.03 Slip gain Real 0…200 % 1 = 1%
97.04 Voltage reserve Real -4…50 % 1 = 1%
97.05 Flux braking List 0…2 - 1 = 1
97.10 Signal injection List 0…4 - 1 = 1
97.11 TR tuning Real 25…400 % 1 = 1%
97.13 IR compensation Real 0.00…50.00 % 100 = 1%
97.15 Motor model temperature
adaptation
List 0...1 - 1 = 1
97.16 Stator temperature factor Real 0...200 % 1=1%
97.17 Rotor temperature factor Real 0...200 % 1=1%
97.20 U/F ratio List 0…1 - 1 = 1
98 User motor parameters
98.01 User motor model mode List 0…1 - 1 = 1
98.02 Rs user Real 0.0000…0.50000 p.u. 100000 = 1
p.u.
98.03 Rr user Real 0.0000…0.50000 p.u. 100000 = 1
p.u.
No. Name Type Range Unit FbEq32
