372 Fieldbus control through the embedded fieldbus interface (EFB)
The new settings will take effect when the drive is powered up the next time, or when
they are validated by parameter 58.06 Communication control (Refresh settings).
Setting the drive control parameters
After the embedded fieldbus interface has been set up, check and adjust the drive
control parameters listed in the table below. The Setting for fieldbus control column
gives the value or values to use when the embedded fieldbus signal is the desired
source or destination for that particular drive control signal. The
Function/Information column gives a description of the parameter.
58.06 Communication
control
Refresh settings Validates the settings of the configuration
parameters.
Parameter
Setting for
fieldbus control
Function/Information
CONTROL COMMAND SOURCE SELECTION
20.01 Ext1
commands
Embedded fieldbus Selects fieldbus as the source for the start
and stop commands when EXT1 is selected
as the active control location.
20.02 Ext2
commands
Embedded fieldbus Selects fieldbus as the source for the start
and stop commands when EXT2 is selected
as the active control location.
SPEED REFERENCE SELECTION
22.11 Ext1 speed ref1 EFB ref1 Selects a reference received through the
embedded fieldbus interface as speed
reference 1.
22.18 Ext2 speed ref1 EFB ref1 Selects a reference received through the
embedded fieldbus interface as speed
reference 2.
TORQUE REFERENCE SELECTION
26.11 Torque ref1
source
EFB ref1 Selects a reference received through the
embedded fieldbus interface as torque
reference 1.
26.12 Torque ref2
source
EFB ref1 Selects a reference received through the
embedded fieldbus interface as torque
reference 2.
FREQUENCY REFERENCE SELECTION
28.11 Ext1 frequency
ref1
EFB ref1 Selects a reference received through the
embedded fieldbus interface as frequency
reference 1.
28.15 Ext2 frequency
ref1
EFB ref1 Selects a reference received through the
embedded fieldbus interface as frequency
reference 2.
Parameter
Setting for
fieldbus control
Function/Information
