Parameters 269
0…255 Node address (values 1…127 are allowed). 1=1
58.04 Baud rate Selects the transfer rate of the Modbus fieldbus link.
Changes to this parameter take effect after the control unit
is rebooted or the new settings validated by parameter
58.06 Communication control (Refresh settings).
Note: If parameter 58.01 = [3] CANopen, the Baud rate
range and the selection list item names change. See Baud
rate below.
19.2 kbps
4.8 kbps 4.8 kbit/s. 1
9.6 kbps 9.6 kbit/s. 2
19.2 kbps 19.2 kbit/s. 3
38.4 kbps 38.4 kbit/s. 4
57.6 kbps 57.6 kbit/s. 5
76.8 kbps 76.8 kbit/s. 6
115.2 kbps 115.2 kbit/s. 7
58.04 Baud rate Defines the communication speed of the CANopen bus.
Changes to this parameter take effect after the control unit
is rebooted or the new settings validated by parameter
58.06 Communication control (Refresh settings).
125 kbps
50 kbps 50 kbit/s. 1
100 kbps 100 kbit/s. 2
125 kbps 125 kbit/s. 3
250 kbps 250 kbit/s. 4
500 kbps 500 kbit/s. 5
1 Mbps 1 Mbit/s. 6
58.05 Parity Selects the type of parity bit and number of stop bits.
Changes to this parameter take effect after the control unit
is rebooted or the new settings validated by parameter
58.06 Communication control (Refresh settings).
Note: If parameter 58.01 = [3] CANopen, this parameter is
hidden.
8 EVEN 1
8 NONE 1 Eight data bits, no parity bit, one stop bit. 0
8 NONE 2 Eight data bits, no parity bit, two stop bits. 1
8 EVEN 1 Eight data bits, even parity bit, one stop bit. 2
8 ODD 1 Eight data bits, odd parity bit, one stop bit. 3
58.06 Communication
control
Takes changed EFB settings in use, or activates silent
mode.
Enabled
Enabled Normal operation. 0
Refresh settings Refreshes settings (Modbus parameters 58.01…58.05,
58.14…58.17, 58.25, 58.28…58.34, CANopen
parameters 58.03, 58.04, 58.06, 58.14, 58.23...58.29,
58.70...58.93 and 58.101...58.124) and takes changed
EFB configuration settings in use.
Reverts automatically to Enabled
.
1
No. Name/Value Description Default
FbEq 16
