Technical data
118
Terminal and lead-through data for the power cables
Input, motor and brake resistor cable terminal sizes (per phase), maximum accepted
cable and tightening torques are given below.
Two-hole 1/2 inch diameter cable lugs can be used.
Terminal data for the control cables
See page 87.
U1, V1, W1, U2, V2, W2, UDC+/R+, UDC-, R- Grounding PE
Number of holes
per phase
Max. cable Screw Tightening
torque
Screw Tightening
torque
mm
2
N·m N·m
3 3×240 M12 50...75 M10 30...44
Max. cable U1, V1, W1, U2, V2, W2, UDC+/R+, UDC-, R- Grounding PE
Screw Tightening torque Screw Tightening torque
kcmil/AWG lbf·ft lbf·ft
3 × 700 MCM 1/2 37...55 3/8 22...32
Electrical power network specification
Voltage (U
1
) 380/400/415/440/460/480/500 VAC 3-phase ± 10%
Rated conditional short-
circuit current (IEC 60439-1)
65 kA when protected by fuses given in the fuse tables
Short-circuit current
protection (UL 508C,
CSA C22.2 No. 14-05)
US and Canada: The drive is suitable for use on a circuit capable of delivering not more
than 100 kA symmetrical amperes (rms) at 600 V maximum when protected by fuses
given in the table Fuses (UL).
Frequency 48 to 63 Hz, maximum rate of change 17%/s
Imbalance Max. ± 3% of nominal phase to phase input voltage
Fundamental power factor
(cos phi
1
)
0.98 (at nominal load)
Motor connection data
Motor types Asynchronous AC induction motors, permanent magnet synchronous motors
Voltage (U
2
) 0 to U
1
, 3-phase symmetrical, U
max
at the field weakening point
Frequency DTC mode: 0 to 3.2 · f
f
. Maximum frequency 500 Hz (120 Hz with du/dt or sine filter). Low
motor noise mode is recommended with high frequencies (see also Firmware manual).
f
f
=
f
f
: frequency at field weakening point; U
N
: electrical power system voltage; U
m
: rated
motor voltage; f
m
: rated motor frequency
Frequency resolution 0.01 Hz
Current See section Ratings.
Field weakening point 0…500 Hz
Switching frequency 3 kHz (typically)
U
N
U
m
· f
m
