ABB ACS850 Hardware Manual

Introduction to the manual
24
Terms and abbreviations
Term/Abbreviation Explanation
EMC Electromagnetic Compatibility
EMI Electromagnetic Interference
FIO-01 Optional digital I/O extension
FIO-11 Optional analogue I/O extension
FIO-21 Optional analog and digital I/O extension
FEN-01 Optional TTL encoder interface
FEN-11 Optional absolute encoder interface
FEN-21 Optional resolver interface
FCAN-0x Optional CANopen adapter
FDNA-0x Optional DeviceNet adapter
FENA-0x Optional Ethernet/IP adapter
FLON-0x Optional LonWorks adapter
FSCA-0x Optional Modbus adapter
FPBA-0x Optional PROFIBUS DP adapter
Frame (size) Size of the drive module. The drive modules described in this manual are
of frame size G.
FSCA-0x Optional Modbus adapter
IGBT Insulated Gate Bipolar Transistor; a voltage-controlled semiconductor type
widely used in inverters due to their easy controllability and high switching
frequency.
I/O Input/Output
JCU The control unit of the drive module. The external I/O control signals are
connected to the JCU, or optional I/O extensions mounted on it.
JINT Main circuit board
JMU-xx The memory unit attached to the control unit of the drive
RFI Radio-frequency interference
HTL High-threshold logic
TTL
Transistor-transistor logic
