Installation checklist
95
Installation checklist
What this chapter contains
This chapter contains a list for checking the mechanical and electrical installation of
the drive.
Go through the checklists below together with another person. Follow the Safety
instructions on the first pages.
Mechanical installation
Cabinet construction
Checks for cabinet construction are listed below.
Instrumentation, busbars and cabling
Checks for instrumentation, busbars, cabling, clearances and creepage distances
are listed below. For more information, see chapter Planning the electrical
installation.
1 Cabinet construction
1.1 Frame, wall, floor and roof structures, busbar enclosures and cable entries are correct and completely
assembled.
1.2 The drive module is fastened properly to the cabinet. (See Planning the cabinet installation and
Mechanical installation.)
1.3 Mechanical joints are tightened and not broken.
1.4 Parts are clean and painted surfaces not scratched.
The cabinet frame and parts which are in metal to metal contact with the frame (for example seams,
component fixing points on assembly plates, back of control unit mounting plate) are not finished with
non-conducting paint or material.
1.5 Degree of protection (IPxx)
1.6 There is a sufficient number of supports, bolts and nuts for cables.
2 Instrumentation
2.1 Type and number of option modules and other equipment is correct. Option modules and other
equipment are not damaged.
2.2 Option modules and terminals are labelled correctly.
2.3 The placement of option modules and other equipment inside the cabinet and on the cabinet door is
correct.
2.4 The mounting of option modules and other equipment is correct.
