ABB ACS850 Hardware Manual

Mechanical installation
49
Unpack the package as follows:
• Cut the bands (A).
• Unpack the additional boxes (B).
• Remove the sheathing by lifting it (C).
• Fasten lifting hooks to the drive module lifting eyes (D) and lift the module to the
installation place.
Checking the delivery
Check that all items listed under section Moving and unpacking the unit are present.
Check that there are no signs of damage. Before attempting installation and
operation, check the information on the type designation label of the drive to verify
that the unit is of the correct type.
Attaching the warning stickers
Attach the residual voltage warning sticker of the local language onto the drive
module front cover.
Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: info@clrwtr.com

ABB ACS850 Specifications

General

Safety	STO (Safe Torque Off)
Communication	CANopen
Enclosure	IP21
Output Voltage	Up to 1000 V DC
Protection Features	Overcurrent, Overvoltage, Undervoltage
Cooling Method	Air or liquid cooling
Input Voltage	380 to 690 V AC
