Electrical installation
92
Routing the control cables
Remove outer jacket of cable at clamp to
expose cable shield. Tighten clamp to
1.5 N·m (13 lbf·in)
Run cables through the cover
mounting bracket
Use shrink tubing or tape to
contain strands
