Parameters 175
16.09 DIO1 function (Visible when 16.01 Module 3 type = FIO-01 or FIO-11)
See parameter 14.09 DIO1 function.
Input
16.11 DIO1 output source (Visible when 16.01 Module 3 type = FIO-01 or FIO-11)
See parameter 14.11 DIO1 output source.
Not energized
16.12 DIO1 ON delay (Visible when 16.01 Module 3 type = FIO-01 or FIO-11)
See parameter 14.12 DIO1 ON delay.
0.0 s
16.13 DIO1 OFF delay (Visible when 16.01 Module 3 type = FIO-01 or FIO-11)
See parameter 14.13 DIO1 OFF delay.
0.0 s
16.14 DIO2 function (Visible when 16.01 Module 3 type = FIO-01 or FIO-11)
See parameter 14.14 DIO2 function.
Input
16.16 DIO2 output source (Visible when 16.01 Module 3 type = FIO-01 or FIO-11)
See parameter 14.16 DIO2 output source.
Not energized
16.17 DIO2 ON delay (Visible when 16.01 Module 3 type
= FIO-01 or FIO-11)
See parameter 14.17 DIO2 ON delay.
0.0 s
16.18 DIO2 OFF delay (Visible when 16.01 Module 3 type = FIO-01 or FIO-11)
See parameter 14.18 DIO2 OFF delay.
0.0 s
16.19 DIO3 function (Visible when 16.01 Module 3 type = FIO-01)
See parameter 14.19 DIO3 function.
Input
16.19 AI supervision
function
(Visible when 16.01 Module 3 type = FIO-11 or FAIO-01)
See parameter 14.19 AI supervision function.
No action
16.20 AI supervision
selection
(Visible when 16.01 Module 3 type = FIO-11 or FAIO-01)
See parameter 14.20 AI supervision selection.
0000 0000b
16.21 DIO3 output source (Visible when 16.01 Module 3 type = FIO-01)
See parameter 14.21 DIO3 output source.
Not energized
16.21 AI tune (Visible when 16.01 Module 3 type = FIO-01 or FAIO-01)
See parameter 14.21
DIO3 output source.
No action
16.22 DIO3 ON delay (Visible when 16.01 Module 3 type = FIO-01)
See parameter 14.22 DIO3 ON delay.
0.0 s
16.22 AI force selection (Visible when 16.01 Module 3 type = FIO-11 or FAIO-0 1)
See parameter 14.22 AI force selection.
0000b
16.23 DIO3 OFF delay (Visible when 16.01 Module 3 type = FIO-01)
See parameter 14.23 DIO3 OFF delay.
0.0 s
16.24 DIO4 configuration (Visible when 16.01 Module 3 type = FIO-01)
See parameter 14.24 DIO4 function.
Input
16.26 DIO4 output source (Visible when 16.01 Module 3 type = FIO-01)
See parameter 14.26 DIO4 output source.
Not energized
16.26 AI1 actual value (Visible when 16.01 Module 3 type = FIO-11 or FAIO-0 1)
See parameter 14.26 AI1 actual value.
-
16.27 DIO4 ON delay (Visible when 16.01 Module 3 type = FIO-01)
See parameter
14.27 DIO4 ON delay.
0.0 s
16.27 AI1 scaled value (Visible when 16.01 Module 3 type = FIO-11 or FAIO-0 1)
See parameter 14.27 AI1 scaled value.
-
16.28 DIO4 OFF delay (Visible when 16.01 Module 3 type = FIO-01)
See parameter 14.28 DIO4 OFF delay.
0.0 s
16.28 AI1 force data (Visible when 16.01 Module 3 type = FIO-11 or FAIO-01)
See parameter 14.28 AI1 force data.
0.000 mA
No. Name/Value Description Def/
FbEq16

ABB ACS880 PCP Specifications

General

Output current	Up to 5200 A
Input voltage	380-690 V
Power range	5600 kW
Cooling method	Air or liquid
Protection class	IP21, IP54
Communication interfaces	Ethernet, CANopen
