202 Parameters
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1). 11
Other [bit] Source selection (see Terms and abbreviations on page
101).
-
22.74 Motor potentiometer
down source
Selects the source of motor potentiometer down signal.
0 = No change
1 = Decrease motor potentiometer value. (If both the up
and down sources are on, the potentiometer value will not
change.)
For the selections, see parameter 22.73 Motor
potentiometer up source.
Not selected
22.75 Motor potentiometer
ramp time
Defines the change rate of the motor potentiometer. This
parameter specifies the time required for the motor
potentiometer to change from minimum (22.76) to
maximum (22.77). The same change rate applies in both
directions.
60.0 s
0.0 … 3600.0 s Motor potentiometer change time. 10 = 1 s
22.76 Motor potentiometer
min value
Defines the minimum value of the motor potentiometer. -1500.00
-32768.00...
32767.00
Motor potentiometer minimum. 1 = 1
22.77 Motor potentiometer
max value
Defines the maximum value of the motor potentiometer. 1500.00
-32768.00...
32767.00
Motor potentiometer maximum. 1 = 1
22.80 Motor potentiometer
ref act
Displays the output of the motor potentiometer function.
(The motor potentiometer is configured using parameters
22.71…22.74.)
This parameter is read-only.
-
-32768.00...
32767.00
Value of motor potentiometer. 1 = 1
22.81 Speed reference act
1
Displays the value of speed reference source 1 (selected
by parameter 22.11 Speed ref1 source). See the control
chain diagram on page 476.
This parameter is read-only.
-
-30000.00
…30000.00 rpm
Value of reference source 1. See par.
46.01
22.82 Speed reference act
2
Displays the value of speed reference source 2 (selected
by parameter 22.12 Speed ref2 source). See the control
chain diagram on page 476.
This parameter is read-only.
-
-30000.00
…30000.00 rpm
Value of reference source 2. See par.
46.01
No. Name/Value Description Def/
FbEq16
