ABB ACS880 PCP User Manual

286 Parameters
Speed The scaling is defined by parameter 46.01 Speed scaling.4
Frequency The scaling is defined by parameter 46.02 Frequency
scaling.
5
50.05 FBA A ref2 type Selects the type and scaling of reference 2 received from
fieldbus adapter A. The scaling of the reference is defined
by parameters 46.01…46.03, depending on which
reference type is selected by this parameter.
For the selections, see parameter 50.04 FBA A ref1 type.
Speed or
frequency
50.07 FBA A actual 1 type Selects the type/source and scaling of actual value 1
transmitted to the fieldbus network through fieldbus
adapter A.
Speed or
frequency
Speed or frequency Type/source and scaling are chosen automatically
according to the currently active operation mode as
follows:
0
Transparent The value selected by parameter 50.10 FBA A act1
transparent source is sent as actual value 1. No scaling is
applied (the 16-bit scaling is 1 = 1 unit).
1
General The value selected by parameter 50.10 FBA A act1
transparent source is sent as actual value 1 with a 16-bit
scaling of 100 = 1 unit (ie. integer and two decimals).
2
Torque 01.10 Motor torque is sent as actual value 1. 3
Speed 01.01 Motor speed used is sent as actual value 1. The
scaling is defined by parameter 46.01 Speed scaling.
4
Frequency 01.06 Output frequency is sent as actual value 1. The
scaling is defined by parameter 46.02 Frequency scaling.
5
Position Motor position is sent as actual value 1. See parameter
90.06 Motor position scaled.
6
50.08 FBA A actual 2 type Selects the type/source and scaling of actual value 2
transmitted to the fieldbus network through fieldbus
adapter A.
For the selections, see parameter 50.07 FBA A actual 1
type.
Speed or
frequency
50.09 FBA A SW
transparent source
Selects the source of the fieldbus status word when the
fieldbus adapter is set to a transparent communication
profile eg. by its configuration parameters (group 51 FBA A
settings).
Not selected
Not selected No source selected. -
Other Source selection (see Terms and abbreviations on
page 101).
-
No. Name/Value Description Def/
FbEq16
Operation mode
(see par. 19.01)
Actual 1 type
(source)
Scaling
Speed control
Speed
(01.01 Motor speed used)
46.01 Speed scaling
Torque control
Frequency control
Frequency
(01.06 Output frequency)
46.02 Frequency scaling

ABB ACS880 PCP Specifications

General

Output current	Up to 5200 A
Input voltage	380-690 V
Power range	5600 kW
Cooling method	Air or liquid
Protection class	IP21, IP54
Communication interfaces	Ethernet, CANopen
