ABB ACS880 PCP User Manual

288 Parameters
50.18 FBA A actual value 2 Displays raw (unmodified) actual value ACT2 sent by
fieldbus adapter A to the master (PLC) if debugging is
enabled by parameter 50.12 FBA A debug mode.
This parameter is read-only.
-
-2147483648
…2147483647
Raw ACT2 sent by fieldbus adapter A to master. -
50.21 FBA A timelevel sel Selects the communication time levels.
In general, lower time levels of read/write services reduce
CPU load. The table below shows the time levels of the
read/write services for cyclic high and cyclic low data with
each parameter setting.
* Cyclic high data consists of fieldbus Status word, Act1
and Act2.
** Cyclic low data consists of the parameter data mapped
to parameter groups 52 FBA A data in and 53 FBA A data
out, and acyclic data.
Control word, Ref1 and Ref2 are handled as interrupts
generated on receipt of cyclic high messages.
Normal
Normal Normal speed. 0
Fast Fast speed. 1
Very fast Very fast speed. 2
Monitoring Low speed. Optimized for PC tool communication and
monitoring usage.
3
50.31 FBA B enable Enables/disables communication between the drive and
fieldbus adapter B, and specifies the slot the adapter is
installed into.
Disable
Disable Communication between drive and fieldbus adapter B
disabled.
0
Option slot 1 Communication between drive and fieldbus adapter B
enabled. The adapter is in slot 1.
1
Option slot 2 Communication between drive and fieldbus adapter B
enabled. The adapter is in slot 2.
2
Option slot 3 Communication between drive and fieldbus adapter B
enabled. The adapter is in slot 3.
3
50.32 FBA B comm loss
func
Selects how the drive reacts upon a fieldbus
communication break. The time delay is defined by
parameter 50.33 FBA B comm loss timeout.
No action
No action No action taken. 0
Fault Communication break detection active. Upon a
communication break, the drive trips on a 7520 FBA B
communication fault and coasts to a stop.
1
No. Name/Value Description Def/
FbEq16
Selection Cyclic high * Cyclic low **
Monitoring 10 ms 2 ms
Normal 2 ms 10 ms
Fast 500 µs 2 ms
Very fast 250 µs 2 ms

ABB ACS880 PCP Specifications

General

Output current	Up to 5200 A
Input voltage	380-690 V
Power range	5600 kW
Cooling method	Air or liquid
Protection class	IP21, IP54
Communication interfaces	Ethernet, CANopen
