58.27 EFB ref2 type Selects the type and scaling of reference 2 received
through the embedded fieldbus interface.
The scaled reference is displayed by 03.10 EFB reference
2.
For the selections, see parameter 58.26 EFB ref1 type.
Torq ue
58.28 EFB act1 type Selects the type of actual value 1. Speed or
frequency
Speed or frequency Type/source and scaling are chosen automatically
according to the currently active operation mode as
follows:
0
Transparent The value selected by parameter 58.31 EFB act1
transparent source is sent as actual value 1. No scaling is
applied (the 16-bit scaling is 1 = 1 unit).
1
General The value selected by parameter 58.31 EFB act1
transparent source is sent as actual value 1 with a 16-bit
scaling of 100 = 1 unit (ie. integer and two decimals).
2
To rq u e 01.10 Motor torque is sent as actual value 1. The scaling is
defined by parameter 46.03.
3
Speed 01.01 Motor speed used is sent as actual value 1. The
scaling is defined by parameter 46.01 Speed scaling.
4
Frequency 01.06 Output frequency is sent as actual value 1. The
scaling is defined by parameter 46.02 Frequency scaling.
5
Position Motor position is sent as actual value 1. See parameter
90.06 Motor position scaled.
6
58.29 EFB act2 type Selects the type of actual value 2.
For the selections, see parameter 58.28 EFB act1 type.
Torq ue
58.30 EFB status word
transparent source
Selects the source of the status word when 58.25 Control
profile is set to Transparent.
Not selected
Not selected None. 0
Other Source selection (see Terms and abbreviations on page
101).
-
58.31 EFB act1 transparent
source
Selects the source of actual value 1 when 58.28 EFB act1
type is set to Transparent or General.
Not selected
Not selected None. 0
Other Source selection (see Terms and abbreviations on page
101).
-
58.32 EFB act2 transparent
source
Selects the source of actual value 1 when 58.29 EFB act2
type is set to Transparent or General.
Not selected
Not selected None. 0
Other Source selection (see Terms and abbreviations on page
101).
-
No. Name/Value Description Def/
FbEq16
Operation mode
(see par. 19.01)
Actual 1 type
(source)
Scaling
Speed control
Speed
(01.01 Motor speed used)
46.01 Speed scaling
Torque control
Frequency control
Frequency
(01.06 Output frequency)
46.02 Frequency scaling

ABB ACS880 PCP Specifications

General

Output current	Up to 5200 A
Input voltage	380-690 V
Power range	5600 kW
Cooling method	Air or liquid
Protection class	IP21, IP54
Communication interfaces	Ethernet, CANopen
