ABB ACS880 PCP User Manual

Fault tracing 435
D101 Pressure fault Measured 09.09 Pressure is
over than defined limits.
Fault condition has been
fulfilled.
Check for problem in measurement
device.
Check for high gas content.
Check warning function setting in
parameters.
See 76.02 Pressure protection
latching.
D102 Underload fault 78.02 Underload function is
set to fault. Point of actual
09.01 Rod torque / 09.05
Rod speed values falls below
user defined curve
(parameters 78.03 - 78.08)
for a time period defined by
parameter 78.08 Underload
delay time.
Check parameter settings.
Check setting of 78.02 Underload
function.
Check mechanical condition of the
pump.
Check fluid condition.
D103 Rod torque 1 limit fault 09.01 Rod torque is lower or
higher than 77.04 Rod torq1
limit and 09.05 Rod speed is
lower that 77.05 Rod torq1
speed for a period of time
defined by parameter 77.06
Rod torq1 delay time.
See parameters 77.02 - 77.06.
Check warning function setting in
parameters and set values as
required.
Check mechanical condition of the
pump.
D104 Rod torque 2 limit fault 77.07 Rod torq2 function has
been triggered more than
77.13 Rod torq2 limit counter
times during 77.14 Rod torq2
time window.
Check parameter settings and set
values as required.
D105 Brake confirmation fault Mechanical brake (if present)
did not pass Pump backspin
control procedure.
Check operational condition of
mechanical brake (if present).
Check parameters 74.21...74.25.
Code
(hex)
Fault Cause What to do

ABB ACS880 PCP Specifications

General

Output current	Up to 5200 A
Input voltage	380-690 V
Power range	5600 kW
Cooling method	Air or liquid
Protection class	IP21, IP54
Communication interfaces	Ethernet, CANopen
